HITACHI ZX250 LC-6 Crawler Excavators for Sale
The Hitachi ZX250LC-6 has strong excavation power and lifting reach and comes under the medium-large crawler excavator category. HITACHI ZX250 LC-6 crawler excavators for sale are equipped with a 177 HP diesel engine to uphold a 59,525 lb operating weight. Its advanced hydraulic system and standard bucket can perform extensive earthworks all day.
The Hitachi company targets the ZAXIS-6 series to deliver reliable power with the least fuel consumption (an average of 4.0 gallons/hour). Mico Cranes and Equipment, TX, has ZX250LC-6 excavators with built-in ZXLink telematics to monitor performance, idling, usage hours, and fuel through remote connections.
Key Specifications of ZX250LC-6 Crawler Excavators
This Hitachi product is evidence of their Fuel Advantage program, which has strong telemetric support to reduce the total cost of ownership. Moreover, ZX250LC-6 has advanced features to increase utilization and reduce downtime. The buyers need to understand specifications to make informed decisions.
| Specifications | Value |
| Engine | Isuzu 4HK1 (4-cylinder internal combustion) |
| Engine Power | 177 HP (132 kW) |
| Operating Weight | 59,525 lb |
| Air Emission Compliance | Tier 4 / EU Stage IV |
| Average Travel Speeds | 3.4 km/h |
| Digging Depth | 25 ft 0 in (7.61 m) |
| Lifting Reach | 35 ft 3 in (10.75 m) |
| Bucket Digging Force | 42,264 lb |
| Drawbar Pull | 21,924 kg (48,334 lb) |
| Fuel Tank | 510 L |
| Hydraulic System | Pumps with three variable-displacement and axial piston |
| Hydraulic Operating Pressures | 4,975 psi |
| Machine Dimensions | WXH 3,390 mm X 3,370 mm |
| Ground Clearance | 460 mm |
| Tailswing Radius | 3,140 mm (10 ft 4 in) |
| Ground Bearing Pressure | 37.6 kPa (~5.45 psi) |
1. Fuel-Efficient Engine without DPF
The manufacturer fortified this crawler excavator with an Isuzu 4HK1 engine with four combustion chambers. The advanced integrated SCR technology maintains Tier 4 Final conformity. Moreover, this powertrain is designed to remove the need for a diesel particulate filter (DPF), which means minimal regular filter replacement. Thus, the ZX250LC-6 facilitates its users with less fuel consumption and less maintenance expenses.
2. Powerful Hydraulic
The ZX250LC-6 can effectively dig complex layers of soil or rocks with a 42,264 lb bucket breakout force. Moreover, its arm is boosted with 25,628 lb crowd force for flawless mobility. The advanced hydraulic system can generate up to 4,975 psi fluid flow rate for powerful and precise outcomes.
Delivers up to 42,264 lb (188 kN) bucket breakout force and 25,628 lb (114 kN) arm crowd force. Hitachi company outfits three variable-displacement axial piston pumps in the hydraulic system for a smooth cycle time. The speedy performance reduces the excessive load on the machine and unnecessary fuel burning.
3. Operator Comfort and Control
Operator comfort is essential to improving productivity even on challenging job sites. The ZX250LC-6 is engineered with a spacious cab, climate control, and ergonomic seating. The digital controls and multifunctional LCD monitor over the dashboard provide complete machine control. Improved visibility reduces occupational hazards and injuries.
4. Integrated ZXLink™ Telematics System
For safety and performance reliability, remote access to various machine parameters is possible around the clock with integrated telematics.
The integrated Zxlinktm allows you to monitor the excavator from any location. It offers up-to-date information for fleet managers to monitor performance, plan timely services, and prevent unplanned malfunctions.
5. Simple and Easy Maintenance
Indeed, longer servicing intervals reduce Hitachi excavators’ downtime. A sturdy undercarriage and strengthened construction ensure a long lifespan. The ground-level points for oil and fluid change lessen the time and energy involved in regular maintenance protocols.
6. Strong Versatility and Application
The ZX250LC-6 is designed to perform various tasks, including site preparation, installation of utilities, mining, earthmoving, and construction. It is versatile since it may be used with many accessories, including buckets, mechanical wrenches, and thumbs. It is ideal for intermediate to large-scale excavations because of its 25-foot digging depth.
Real-World Applications of Hitachi ZX250LC-6
You may observe exactly how the Hitachi ZX250LC-6 works to facilitate professionals from various industries. These applications demonstrate the capabilities and practical applications of the used track excavator for sale in Houston, Texas:
1. Quarrying and Mineral Loading
The ZX250LC-6 loads debris into trucks in Icelandic volcanic rock mining. Its robust undercarriage, practical hydraulic functions, and powerful bucket pullout strength enable numerous bucket-loading operations without severe malfunctions.
2. Foundation Excavation
The contractors utilized it to excavate groundwork for new structures. When laying foundations, the subsurface needs reliable strength to uphold the building load. This crawler excavator has outstanding digging and lifting capacity.
3. Road Site Preparation
Using this technique, excavators are deployed to widen and raise access roads. The professional fills up the road verges with dirt before laying asphalt. These duties require stability, lift capability, and reach (particularly on different grades).
4. Soft Ground Work
The wide track with strong external surfaces enables the experts to maneuver over soft and wet surfaces to conduct drainage supply work. Indeed, the wheel excavators sink into smooth surfaces. The ZX250LC-6 has a reliable undercarriage design to handle slippery terrain.
5. General Construction Use
Hitachi focuses on general construction operations while manufacturing the ZX250LC-6. It can outperform in site clearance, earthmoving, and structural development. It is considered a “highly versatile” crawler excavator with multiple “industry solutions.”
6. Cold-Climate Remote Operation
This excavator’s engine and hydraulic system have a recirculation system that prevents the lubricants from frosting in severe cold weather.
Why Choose Hitachi ZX250LC-6 Crawler Excavators?
The crawler excavators are designed to handle challenging operations over uneven and harsh surfaces. With field-tested performance results, it is proven that Hitachi ZX250LC-6 excels other comparable models for lower operating costs, high productivity, operator comfort, and uptime. Join us in understanding these claims in more detail.
1. Lower Lifetime Operating Cost
The most appealing features of this excavator are its Dash-6 hydraulic platform for precise work and an Isuzu Tier-4 Final engine to meet regulatory conformity. Hitachi cited ZX250LC-6, an ECO mode crawler excavator that can reduce fuel consumption by up to 19% compared to its older models. The optimized fueling system will reduce the overall expenses of any project.
2. Simpler, Less Maintenance System
Hitachi’s products are always user-friendly in operation and maintenance, and have low-fund-level service ports. Moreover, this model engine doesn’t have a diesel particulate filter (DPF), saving time for its replacement. The users will experience minimal chances of regeneration-related downtime.
3. Strong Hydraulic for High Productivity
High oscillation torque, superior bucket splitting power, and arm throng forces testify to its advanced hydraulic system. The operations are fast and flawless without any mishaps. A wide bucket loading capacity improves truck hauling.
4. Telematics Measurable Utilization
ZXLink diagnostics are an integrated feature that monitors the excavator’s current location, fuel usage, digging depth, and idle time. This remote assistance can manage early fault identification, which can be reported with fast real-time data tracking.
By reducing inconveniences, fleet managers can enhance fleet ROI and lower unforeseen expenses. Telematics transforms “hope” into quantifiable performance improvements.
5. Designed for Easy Repairs
The company designed the engine enclosure to protect it from dust and debris. Moreover, the crawler excavator’s structure is so simple that technicians require less time and energy to repair it. The worldwide customer support network and easy availability of spare parts improve this model’s resale value and buyer demand.
6. Real-World Proven Results
The ZX250LC-6 can be chosen for reliability and consistency in harsh, cold-climate operations. This strength is proven by its successful roadway construction project in Iceland. It performs well in such challenging conditions and delivers outstanding results.
Comparative Analysis with Market Available Options
Select the Hitachi ZX250LC-6 for noticeable operating cost savings, unparalleled uptime, and convenient serviceability. These features are really the triggering factor that distinguishes this model from others.
| Feature | Hitachi ZX250LC-6 | Caterpillar 320 | Komatsu PC210 |
| Engine Power | 177 HP | 172 HP | 165 HP |
| Operating Weight | 27,000 kg | 22,600 kg | 24,400 kg |
| Max digging depth | 25.0 ft | 22.0 ft | 21.72 feet |
| Emissions | Tier-4 Final / EU Stage IV | Tier-4 Final / Stage V | Tier-4 Final / Stage V |
| Telematics | ZXLink (built-in telematics) | Cat Product Link / VisionLink | Komtrax |
| Fuel-efficiency | Dash-6 platform with Fuel Advantage and no DPF | Fuel depends on the job. | Auto idle shutdown |
| Serviceability | Ground-level service points | Worldwide dealer serviceability | Komatsu service network supports |
Professional Maintenance and Safe Handling Practices
The Hitachi ZX250LC-6 crawler excavator is reliable, but careful handling is vital to achieving maximum output. Here are some practical tips for keeping the excavator in top-notch condition, increasing uptime, and securing the operator’s safety.
Daily Maintenance Practices
The operators should conduct some routine inspections before starting work. Similarly, thoroughly cleaning and examining extensively used parts is essential after an operation.
| Task | Benefit | Recommended Protocol |
| Visual evaluation of the machine | Early breakdown, rupture, and detectable leaks. | Look for any indications of oil leaking, corrosion, or loose connections in the mechanical pipelines, boom/arm connectors, chassis axles, and swing hinge area. |
| Checks of fluid levels | Avoid damaging parts | Before every shift, check the air, fuel, filters, engine coolant, and hydraulic fluid levels. Use only materials permitted by Hitachi. |
| Clean the radiator and airflow | Avoid overheating. | Clear the area around the cooling unit, thermostat, and engine fan to preserve ventilation and radiator performance, especially in humid settings. |
| Examine the track tension | Decrease suspension wear and preserve traction. | Make sure the track sag is appropriate based on Hitachi’s specifications (the ZX250LC-6 typically has a sag of 35 to 45 mm). Adjust the tension as needed. |
| Greasing important areas | Increase durability and lessen articular wear. | Apply the suggested lithium-based lubricant to all movable parts to control friction. |
Scheduled Maintenance
These services need a specific time period or operational hours to pass. Mostly, the staff need a certified technician or fleet manager to perform them.
| Interval | Actions | Importance |
| 250 hours | Change the engine’s oil and filter cartridges; check the valves and hydraulic connectors of the engine. | Engine wear stabilizes, and the chances of pollutant intervention are eliminated. |
| 500 hours | Check for undercarriage breakdowns, wash the water splitter and fuel filter, and upgrade the hydraulic discharge filters. | Avoids track malfunctions and hydraulic pollution. |
| 1000 hours | Conduct hydraulic sample testing, check radiator and compressor inspection, and any necessary valve pitch adjustments. | Detects wear rapidly before expensive malfunctions. |
| 2000 hours | Complete examination of the hydraulic system, engine, and undercarriage. | Reduce the chances of machine failure and occupational hazards. |
Safe Operating Practices
Always hire a certified operator with considerable experience to meet productivity targets and manage the machine and the nearby people’s well-being.
| Area | Practice | Details |
| Pre-Start | Inspect the machine 360° | Ensure there are no obvious liquid spills, the rotating area is spotless, the stairs are tidy, and the grasp hooks are securely fastened. |
| Startup | Give the engine 10 minutes before starting a warm-up. | This helps the engine and hydraulics reach working conditions, minimizing early wear, particularly in wintertime. |
| Swing & Lift Safety | Maintain the carried weight within the company-defined load chart. | The ZX250LC-6 has detailed instructions about the load chart pasted within the cab interior. |
| Traveling | Maintain a modest, focused boom. | Avoid travelling at high speeds with elevated attachments, keeping your center of gravity lower. Use the slow mode when on uneven ground. |
| Shut Down | Before turning off the engine, let it idle for three to five minutes. | Prolongs engine lifespan by cooling the hydraulic and compressor connections. Never turn off the engine right away after a heavy load. |
| Load Safety | Inspect the coupler performance. | Bucket hooks and attachments should have accurate couplers for job site safety. |
Special Safety Tips for ZX250LC-6
- No DPF Renewal Threats: The Isuzu engine reduces unwanted high-temperature recharge cycles using SCR instead of a DPF. To prevent deformity, make sure the DEF are appropriate.
- Telematics Guarding Warnings: With Zxlinktm, monitor problems like low fluid pressure, excessive heat, or DEF defects. React to notifications immediately to avoid major failures.
- Automatic Idle Shutoff: Turn on these functions via the built-in dashboard to reduce emissions and unnecessary fuel consumption.
- Cold Climate Operation: The gasoline recirculation mechanism in this model is designed to work best in cold temperatures. Before starting procedures, let the diesel engine warm up for a few minutes.
- Swing Brake: Always apply the swing lock when transporting or doing maintenance to prevent unintentional rotation.
Storage and Transport Protocols
- For transportation, use the OEM anchor hooks on the chassis.
- When transporting goods, limit motion space by folding or fastening the boom and stick.
- If prolonged storage is intended, drain the fuel and DEF.
Always park the Hitachi ZX2650LC-6 on a flat, clean surface and use hand brakes for safety. Drop the boom or connected attachment to the ground. Disconnect the battery if it is stored for a long time.
ZX250LC-6 Compatible Attachments and Customization
The work efficiency of previously owned track excavators for sale in Houston, TX, is enhanced with compatible attachments. Moreover, it can perform specialized operations after modifications or retrofits by registered personnel.
Heavy-Duty Buckets
Standard or heavy-duty buckets are added to Hitachi crawler excavators that can hold 0.9 to 1.6 m³ (1.2 to 2.1 yd³). They can dig medium-quality soils and transport the excavated material a considerable distance. They are typically used in heavy-duty mining operations.
Hydraulic Attachments
The experts use hydraulic thumbs to enhance the holding grip of the machine to manage hauling odd-shaped objects. Similarly, powerful breakers are attachments for partial demolition of buildings or concrete retaining walls. A ripper tooth is used to dig through the hardened or compacted soil layers. Tilt rotators enhance the movements of the boom without repositioning the whole machine.
Specialized Attachments
The grapplers, compact wheels, and crusher buckets are unique add-ons for performing specialized tasks. Machines compatible with a wide range of attachments improve the workflow of any construction site. They can manage multiple operations with a single machine and control overall expenses.
Boom and Stick Customization
To perform extensive lifting tasks in challenging conditions, the booms are retrofitted to tolerate the heavy-duty weight without mechanical strain. This increases the boom’s reach for skyscraper construction.
Undercarriage and Hydraulic Enhancements
Extra covering can be added to the undercarriage and suspension to boost their tensile strength. Additional auxiliary hydraulic circuits enhance the attachment coupling and precision of boom and bucket mobility.
Buyer’s Tips for Purchasing a Used HITACHI ZX250LC-6
You can have a reliable used ZX250LC-6 at a far reduced cost that performs comparably to new ones. Indeed, a careful selection of an optimal-performing unit will give you the best return on your investment and the security to outperform in the field.
- Inspect Hour Meter and Service Logs: Machines with reasonable operating hours and a recorded servicing history should be given priority because they frequently exhibit better care and less wear
- Evaluate Undercarriage Condition: Verify the track alignment of bearings, brushes, and chains. A worn undercarriage can considerably raise after-purchase expenses.
- Check Hydraulic System Performance: This Hitachi crawler excavator is highly dependent on hydraulic accuracy for productivity; therefore, look for lag-free, leak-free, and smooth operation.
- Engine Emissions Compliance: For reliable and long-lasting return, confirm the selected unit’s engine health, idle management, and adherence to Tier 4 emission standards. Legal conformity is essential to boost the company’s reputation.
- Telematics and Electronic Features: If the equipment has Zxlink installed, examine machinery information to determine idle time, fuel consumption, and problem history for precise performance insights.
- Test Operational Controls: Remarkably, to guarantee operational reliability, a comprehensive functional test that includes boom movement, excavating cycle, and travel tracking is recommended.
- Assess Structural Integrity: Look for fractures or repairs on the boom, stick, chassis, and welding points. Such signs are red flags and indicate previous extensive use or repairs.
Find Hitachi Crawaler Excavator Near Me
HITACHI ZX250 LC-6 is the most reliable used crawler excavator for sale in Houston, Texas. It can deliver high lifting efficiency and minimal fuel consumption. It is designed to handle challenging terrains with a stable traction system.
Contact Mico Cranes and Equipment, TX, to purchase second-hand heavy machinery for mining, earthmoving, and construction operations. Our ZX250LC-6 excels in the market with comparable power, precision, and durability to other brands’ models with similar specifications.
FAQs
Q1. What is the fuel mileage of the ZX250LC-6 under standard conditions?
The manufacturer has integrated a turbocharged diesel engine that delivers outstanding performance and burns less fuel. Its auto-shutdown under idle conditions reduces fuel combustion. However, it can consume 4.0–5.0 gallons per hour, which may vary with loading limit, terrain conditions, and operator handling practices.
Q2. Can this Hitachi ZX250LC-6 crawler excavator tolerate extreme surrounding environments?
It has an enclosed engine with an outstanding cooling system that protects against dust and high temperatures, ensuring reliable operations under varied conditions. Moreover, the high-efficiency fuel filtration system reduces the contamination of water and dust particles.
Q3. What kind of remote assistance technology does the ZX250LC-6 support?
It has built-in ZXLink™ telematics that can monitor the machine position, loading pattern, fuel usage, idle time, and early error diagnoses. It can also generate timely notifications for preventive and scheduled maintenance practices. Such assistance reduces the occupational hazards and unexpected downtime.
Q4. What are the reasons for this model’s great resale value?
Hitachi offers worldwide customer support and spare parts availability, which increases its market demand. Moreover, its optimal fuel consumption, advanced hydraulics, and less maintenance needs make it the most sought-after crawler excavator.
